Single 40 EMPI D Carburettor Kit - Type 1 Engines

Specifically jetted and prepared EMPI D Carburettors mated to a specially designed and race-proven Isolated Runner Manifold make for a perfect torque-monster combo.

Designed for off-road, but functions just as well on the street.

Single Carburettor Applications require a Vacuum-Assisted Distributor to achieve proper performance.

Each kit comes complete with a specifically prepared EMPI D Carburettor, Velocity Stacks, Manifold, Aluminium Air Clearner with gauze air filter, complete linkage and all necessary gaskets and hardware.

EMPI “D” Series Carburettors

An esthetically beautiful Carburettor!

• High pressure aluminium die cast manufacturing process ensures excellent dimensional accuracy and smooth surfaces.
• Idle Jets on the TOP of the carburettor for easy access with Extended Idle Jet Holders to help prevent clogged jets and increased mid-range performance.
• Extended float bowl vent helps prevent sloshing and keeps dirt from entering the carburettor.
• Large float bowl for extended runs at full throttle.
• 5-6 Progression Ports that allow for extremely smooth acceleration and drivability.
• Brass port ball designed with a special punch head and special installation tooling that `sets` the ball – assuring that it cannot move or allow fuel leakage drip.
• Decompression Valve – eliminates drips caused by pent-up pressure.
• No Enrichment / Choke Circuit – no additional moving parts to worry about.
• Large Fuel Inlet (Banjo) with special sealing washers.
• Brass Hex-Head Mixture Screws

EMPI D 40mm Deluxe Single Carburettor Kit

For use on all Type 1 1600cc to 1835cc engines

• Stock to Mild Build

Factory Jetting

• 162 Main
• 170 Air
• .65 Idle
• 1.50 Inlet Valve
• 55 Pump
• #2 E-Tube
• 30mm Venturies

NOTE: We have added the following jets to your kit if further tuning is needed: 150 Main, .70 Idle

Kits requires twin port manifold end kit, part number AC129360

Special Order, please call for lead time.
